Descrição
Electrical Data:
| Type: | 0.625 λ center feed |
| Radiation: | Omnidirectional |
| Polarization: | Linear vertical |
| Frequency range: | 25.5-30 MHz No tuning required |
| Systems: | 10m-HAM |
| Gain: | 1 to 2 dB higher than conventional 5/8 λ |
| Max Power: | 500 Watts (CW) continuous |
| Grounding protection: | DC-Ground |
| Connector: | UHF-female (SO-239) |
Mechanical Data:
| Materials: | Anodized Aluminium, Copper, Stainless steel, Fiberglass, Thermoplastic UV stabilized |
| Height (approx): | 7360 mm / 24.15 ft |
| Weight (approx): | 3000 gr / 6.61 lb |
| Mounting type: | On-Mast |
